Dunlop Cry Baby 95Q WahWah-Pedal

Dunlop has taken the original Cry Baby Wah and added three of our most popular upgrades: the famous Q Control, which varies the intensity of the wah effect by adjusting the effect's bandpass shape; Volume Boost, for up to +15dB added gain; and our Auto-Return function that automatically engages the effect when you place your foot on the pedal. It all adds up to a versatile, great sounding wah.

Features:

• Powered by one 9-volt battery (accessed via the bottom of the pedal), an AC adapter (Dunlop ECB003/ ECB003E) or a DC Brick™ power supply.
• VOLUME knob controls amount of gain added by BOOST switch, up to 15dB
• VARIABLE Q knob adjusts frequency range of wah wah effect
• BOOST switch increases output as set by the VOLUME knob
• Silent “auto-off” switching puts pedal into bypass mode when you take your foot off
• Input Impedance: 1 MΩ
• Output Impedance: 1 kΩ
• Noise Floor Heel Down: -98 dBV
• Noise Floor Toe Down: -90 dBV
• Bypass Filter Center Frequency: 390 Hz to 2 kHz
• Maximum Gain: 17 dB
• Boost Range: 0.1 dB to 15 dB
• Bypass: Hardwire
• Current Draw: 1.8 mA
• Power Supply: 9 volts DC

Specs:

• Color: Black
• Effect Type: WahWah
• Type: digital Effects Processor
• Theme: Guitars and Basses
