EarthQuaker Devices Afterneath V3 Reverberator

The Earthquaker Afterneath Reverb pedal from Akron, Ohio (USA) has always been special. It simulates the gigantic intervals that rhythmically echo in a cathedral reverb, it simulates the impression of a gigantic cave with many cave with many overlapping echoes. Of course, the user has full control over the size of his reverb room and can decide reverberation chamber and can decide accordingly how long and extended the reverb tail is, whether the highs in the signal are more or somewhat muffled, and whether the individual reflections cut through the echo or reverberate in a more reverberate more washed out.

In addition to improved signal integrity and lower self-noise, the new version 3 of the popular reverb pedal features popular reverb pedal features a 6.3mm jack that accepts both an expression pedal and a CV source. These devices control the drag knob, whose exact operation is determined by the mode switch directly below it. below. Possible modes are Unquantized, Unquantized with Slew, Unquantized, Volt/Octave, Chromatic Scale, Minor Scale, Major Scale (Lydian), Pentatonic Scale, Octaves and Fifths + Octaves. The pitch can be changed and arpeggiated the pitch of the reverb tail, elevating the Afterneath V3 to an instrument in its own right.

Features:

• Very special ambient reverb effect pedal
• atmospheric, spreading, huge and magical cavern sounds
• New "Drag" control with 9 functions (pitch change of reverb tail selectable)
• True Bypass (without tails) or Buffered Bypass (with tails) switchable
• Silent relay switching with automatic momentary detection
• Controls for Length, Diffuse, Dampen, Reflect, Drag, Mix, Mode
• Input: 1x 6.3mm jack (mono) for the instrument signal
• Output: 1x 6.3mm jack (mono) for the instrument signal
• Expression In: 1x 6.3mm jack socket for the expression pedal or CV signals
• Power supply via 9V DC power supply, 2.1mm hollow plug, negative pole (-) inside (not included)
• Battery operation not possible
• Power consumption: 100mA
• dimensions: 121 x 64 x 57 mm
• Weight: 400g (due to robust metal housing)
• Color: Black with yellow decal
• Handmade in Akron, Ohio - USA

Specs:

• Color: Black
• Effect Type: Delay
• Mono/Stereo: 1x IN / 1x OUT (Mono)
• Type: digital Effects Processor
• Theme: Guitars and Basses

Instruction manual / Safety instructions:

• Manual (379.04 KB)
