Marshall DSL 20HR

Marshall DSL 20HR: Compact top for powerful tube sound

The Marshall DSL 20HR is a versatile tube top that is characterized by its rich sound, flexibility and compact design. Whether in the rehearsal room, studio or live performance, this top delivers the typical Marshall signature in a portable format. Thanks to its extensive features and customization options, the DSL 20HR is an ideal choice for musicians looking for a powerful and versatile amplifier.

Tube sound with flexibility

The DSL 20HR offers two independent channels: Ultra Gain for powerful, distorted sound and Classic Gain for warm, clean tones. This flexibility makes it possible to create a wide range of sounds, from smooth clean tones to aggressive high-gain riffs. The Presence and Resonance controls provide additional tonal depth, while the Tone Shift switch offers further sound options to adapt the amplifier to different styles of music.

Power for any environment

With an output power of 20 watts, the DSL 20HR is suitable for both the rehearsal room and smaller stages. Thanks to the integrated power reduction option, the output can be reduced to 10 watts, making the amp perfect for studio applications or quiet rehearsals without sacrificing sound quality.

Effects and connection diversity

The amplifier is equipped with an integrated reverb effect and an effects loop (send/return) to seamlessly integrate external effects into the setup. The three speaker outputs(16 Ohm and 8 Ohm) offer maximum flexibility for different speaker configurations. In addition, the amp has an emulated line out that can be used for direct recording or monitoring.

Robust tube technology

Inside the DSL 20HR, three ECC83 preamp tubes and two EL34 power amp tubes provide the characteristic Marshall tone. These tubes deliver outstanding dynamics and a warm, assertive sound that fits perfectly into any live or studio environment.

Compact and portable design

With its compact dimensions of 500 x 250 x 240 mm and a weight of only 9.7 kg, the DSL 20HR is easy to transport and yet robust enough for intensive everyday stage use. A detachable power cable and the supplied footswitch (PEDL-90012) round off the practical design.

Conclusion: Marshall DSL 20HR - Powerful sound in a compact format

The Marshall DSL 20HR is a versatile top that will delight both beginners and experienced musicians thanks to its tube technology and flexible features. Whether for studio recordings, rehearsals or smaller live performances - this top delivers the classic Marshall sound with modern customization options. With its compact design, robust construction and exceptional sound quality, the DSL 20HR is an excellent choice for any guitarist.

Features:

• All-tube top with 20 watts of output power
• Two channels: Ultra Gain and Classic Gain
• Power reduction option: output power can be reduced to 10 watts
• Presence and resonance control for deeper sound shaping
• Integrated reverb effect
• Effects loop (send/return)
• Tone shift switch for additional sound options
• 3 speaker outputs: 16 Ohm and 8 Ohm
• Emulated line out (3.5 mm) for recording or monitoring
• Inputs: Instrument (6.35 mm), Aux (3.5 mm)
• Tubes: 3 x ECC83 (preamp), 2 x EL34 (power amp)
• Supplied footswitch: PEDL-90012
• Compact dimensions: 500 x 250 x 240 mm
• Weight: 9.7 kg

Specs:

• Impedance: 16 Ω
• Channels: 2
• Effect Processor: no
• Power: 20 W
• Amplification: Tube
• Amp Type: E-Guitar Head
• Headphone Out: no
• digital modelling: no
• Type: Amps
• Theme: Guitars and Basses

Instruction manual / Safety instructions:

• Manual (2 MB)
