Ortofon Nadel VNL TRIX

Ortofon stylus VNL TRIX

The Ortofon VNL TRIX styl us was specially developed for DJs who value maximum reliability, strong performance and maximum mechanical resilience. Equipped with a spherical stylus mounted on a sturdy aluminum stylus carrier and Ortofon's exclusive rubber suspension, the VNL TRIX offers excellent tracking and durability - even under extreme scratching and back cueing.

Thanks to its solid construction, it is ideal for everyday club use or battle setups where absolute precision and stability are required. At the same time, the fluorescent white stylus ensures quick orientation when cueing - even in dark environments or under UV light.

Robustly built for tough use

The VNL TRIX is made to withstand even the toughest DJ techniques. Whether turntablism, performance battles or intensive club sets - this stylus stays reliably in the groove. The spherical cut is particularly resistant to physical stress, making it ideal for DJs who use their turntables to the full.

The Ortofon-exclusive rubber suspension ensures optimum damping and control, while the aluminum stylus carrier provides a stable base for precise signal transmission. The result: premium tracking under all conditions.

Fluorescent stylus for better visibility

The white fluorescent stylus ensures greater visibility when cueing - especially in dark club environments or under UV light. This speeds up cueing and improves control when scratching or rewinding tracks. Function meets style - ideal for visually demanding setups.

Powerful signal and classic DJ sound

With an output voltage of 10 mV, the VNL TRIX delivers a powerful signal - ideal for loud club systems or professional recording situations. The frequency response of 20 Hz to 20 kHz ensures a full, balanced sound with defined bass and clear treble. Even with complex mixes, the sound remains stable and transparent.

The scanning capacity of 100 μm at the recommended tracking pressure underlines the performance quality of this DJ stylus. The recommended tracking force is 4.0 grams, which ensures optimum contact with the record groove and reliable stability - even under heavy use.

Features:

• Output voltage at 1 kHz, 5 cm/s: 10 mV
• Channel separation at 1 kHz: 22 dB
• Frequency response 20 Hz - 20 kHz: +/-3 dB
• Sampling capability at 315 Hz with recommended contact pressure: 100 μm
• Compliance, dynamic, lateral: 12 μm/mN
• Needle tip radius: R 18 μm
• Recommended contact force: 4.0 grams
• Needle suspension: Ortofon exclusive
• Needle color: White (fluorescent)

Specs:

• Stylus type: not specified
• Color: White
• Type: Stylus
• Theme: DJ Equipment
