Palmer PRMMS Mikrofon Splitbox 8 Kanal

The PRMMS8 is a powerful and extremely low-noise 19-inch microphone splitter with 8 balanced XLR inputs. Each input is connected to a direct output and a transformer-isolated output, which allows a high degree of flexibility in use.Thanks to the 4 LINK switches on the front, two channels can be combined with each other. This makes it possible to distribute a single input signal to up to four outputs, for example for FOH, monitoring, recording or radio transmission. Alternatively, two input signals can be summed to one output signal.Condenser microphones can be supplied with phantom power via the direct outputs. To avoid ground loops and interference, each channel is equipped with a ground lift that eliminates interference caused by double earthing.Palmer stands for authentic sound and reliable quality.

Features

• Type: Mic split
• Split type: 1 in 1 +1
• Number of channels: 8
• Number of inputs: 1
• Input connectors: XLR
• Max. input level: +5 dBu
• Number of split outputs per channel: 1
• Number of THRU outputs per channel: 1
• Max. output level: +5 dBu
• Output connections: XLR
• Outputs transformer-balanced: Yes
• Housing material: Sheet steel
• Housing surface: powder-coated
• Dimensions (W x D x H): 483 x 73 x 44.5 mm
• Width: 19"
• Height: 1 U
• Weight: 1.3 kg
• Color: Blue

Scope of delivery

• 1 x Palmer Pro PRMMS 8 microphone splitter

Specs:

• Type: Accessories
• Theme: PA and Sonication

Instruction manual / Safety instructions:

• Manual (737.39 KB)
