Pioneer DJ DDJ-REV7 DJ Controller

The DDJ-REV7 is part of a new series of DJ controllers from the Pioneer DJ brand. Designed to make the most of Serato DJ Pro performance software, this 2-channel unit features a brand new design with large motorized jog wheels and On Jog Display to create a tactile connection between you and your music.

The DDJ-REV series is a new line of DJ controllers with layouts that emulate a professional DJM-S mixer + PLX turntable setup, including dedicated features for open format and scratch DJs. For the first time on a Pioneer DJ controller, the tempo sliders have been moved to the top of the deck sections and rotated horizontally to emulate PLX turntables arranged in a battle configuration. The performance pads have been placed in the mixer section along with the Lever FX paddles, exactly where they are found on the DJM-S series mixers.

If you're looking for a portable setup that faithfully emulates analog turntables and a mixer, the DDJ-REV7 is perfect. Its 7-inch VINYLIZED JOG wheels are motorized and feel great when scratching. The acrylic platter is specially machined to feel like a real analog record, with a spin treatment that easily sticks to your fingertips when you touch it. Plus, the 3.5-inch on-jog display lets you keep track of important information like waveforms, hot cues, and playback positions. You can easily switch between modes to customize the display. Because the displays have an omnidirectional viewing angle, you'll see everything clearly - no matter what angle you're looking from.

When you're in the middle of a complicated scratch routine and want to fire off a sample, you can easily press one of the Instant Scratch buttons on the DDJ-REV7 to trigger your selection of 4 original sounds. They're all built into the controller, meaning they're always available at the touch of a button, and you don't even have to plug in your laptop to use them. If you want to add your own samples to your sets, load them into the Scratch Bank in Serato DJ Pro and play them whenever you want - even if they're full tracks - by tapping the performance pads. Want to spice up your tracks with effects? The DDJ-REV7 includes 22 beat FX, including 3 brand new ones, that let you get creative, increase the drama, and add texture to your performances. There are also 5 popular Sound Color FX for you to play with. And thanks to the advanced audio components, the unit offers the highest sound quality in the entire Pioneer DJ controller lineup.

Features:

• 7-inch turntable with high-resolution MIDI support.
• 1.8kgf・cm (12-inch, 3.5kgf-cm equivalent) torque suitable for 7-inch scratching operation.
• Torque settings (utility settings) : High - Same operating feel as PLX-1000 1.8 kgf・cm; Low - Same operating feel as SL-1200 1.3
kgf・cm.
• Die-cast aluminum platter for stable rotation and high precision.
• Supported software: Serato DJ Pro
• Frequency response: 20 Hz - 20 kHz (USB, LINE, AUX (LINE / PORTABLE), MIC 1, MIC 2)
• Power supply: AC 100 V - 240 V, 50 Hz / 60 Hz
• Power consumption: DC 24 V, 1000 mA
• Maximum dimensions: (W x D x H) 732 x 382.2 x 82.4 mm / 28.8" x 15.0" x 3.2"
• Weight: 10.7 kg / 23.6 lbs
• Accessories: power adapter, power cord, USB cable, quick start guide, safety instructions, Serato DJ Pro Expansion Pack voucher, marker sticker pack

S/N Ratio:
• USB: 110 dB
• LINE: 95 dB:
• PHONO: 84 dB

Total Harmonic Distortion:
• USB: 0.003%.
• LINE: 0.005%.
• PHONO: 0.017%.

Input/ Output Terminals:
• Inputs: LINE x 2 (RCA), PHONO x 2 (RCA), AUX x 1 (RCA), MIC x 1(XLR & 1/4 inch TRS jack), MASTER ×2(XLR, RCA).
• Outputs: BOOTH x 1 (1/4 inch TRS jack), PHONES ×2(1/4 inch stereo jack, 3.5mm stereo mini jack), USB (Type A) x 2
• USB: USB (Type B) x 2

Specs:

• Color: Black
• USB-MIDI: USB and MIDI
• Deck Support: 2
• Sound Card: yes
• Jogwheel: yes
• Set Offer: no
• Type: DJ Hardware / Controller
• Theme: DJ Equipment

Instruction manual / Safety instructions:

• Manual (10.73 MB)
