Apogee Symphony Desktop

The USB-C audio interface offers professional equipment for musicians and producers looking for a high-quality recording and playback solution. With 10 inputs and 14 outputs as well as the high-quality converter and circuit technology of the Symphony series, it takes your audio productions to a new level.

Features:

• 10 In x 14 Out desktop audio interface with high-quality converters and circuit technology from the Symphony series
• Two microphone preamps with up to 75dB gain and variable impedance
• DSP for calculating preamp emulations (British Solid State and 50s American Tube) and Symphony ECS Channel Strip (EQ, compressor, saturation)
• 24 bit/192 kHz recording and playback quality
• Dynamic touch screen display for intuitive operation
• MIDI via USB
• 2 microphone/line inputs (XLR/TRS combo socket)
• DI instrument input with FET stage (6.3 mm TS jack)
• 2 monitor outputs (6.3 mm TRS jack)
• 2 assignable stereo headphone outputs (3.5 mm and 6.3 mm TRS jack)
• Optical inputs/outputs (ADAT and S/P-Dif)
• USB-A host port and USB-C port
• System requirements: min. macOS 10.13, min. Win10 Anniversary, min. iOS 13 (iPad Pro)
• Dimensions (W x D x H): 199 x 125 x 64 mm
• Including Symphony ESC Channel (native) and Symphony Reverb (native), power supply unit (12 V DC) and 2 USB cables

Technical data:

• Recording/playback channels: 10x14
• Number of microphone inputs: 2
• Number of line inputs: 2
• Number of instrument inputs: 2
• Number of line outputs: 2
• Headphone connections: 2
• Phantom power: Yes
• S/PDIF connections: 1
• ADAT connections: 1
• Other interfaces: USB
• Maximum sampling rate: 192 kHz
• Maximum resolution: 24 bit
• USB Bus-Powered: No
• Incl. power supply: Yes
• USB version: 2.0
• Dimensions (W x D x H): 199 x 125 x 64 mm
• Connection format: USB socket type C, type A

Specs:

• Color: Silver
• Rack Mountable: no
• Line Inputs: 2
• Line Outputs: 2
• Mic Inputs: 2
• Phono Inputs: 0
• Instrument Inputs: 3
• digital Output: ADAT / S/PDIF
• digital Input: ADAT
• Headphone Out: yes
• MIDI Inputs: 0 Ports
• MIDI Outputs: 0 Ports
• Host Port: USB
• Number of headphone outputs: 1
• Type: Audio Interface
• Theme: Recording and Studio
