EUROLITE DMX Commander 512 Modernes Theaterlichtpult für 512 DMX-Kanäle

EUROLITE DMX Commander 512 - Modern theater lighting console for 512 DMX channels

The EUROLITE DMX Commander 512 is a powerful and user-friendly lighting control console for demanding applications in theaters, events, clubs or rental companies. It supports up to 512 DMX channels and offers versatile control options for moving lights, LED spotlights, dimmers and effect devices. Thanks to its sophisticated operating structure, colored fader caps and extensive memory options, the Commander 512 is the perfect choice for professional lighting control with a maximum overview.

Versatile control and intuitive operation

The DMX Commander 512 offers 57 programmable scenes/chases with up to 767 cues, which are organized on a total of 9 pages. The differently coloured fader caps (included in the scope of delivery) help you to categorize your show elements by colour and identify them at a glance. Thanks to status LEDs, you can keep track of complex setups at all times.

Manual, musical or time-based control

Chase playback can be controlled manually, by music or by timer. An integrated microphone and a 6.3 mm jack input are available for music control. The beat control can also be controlled via the practical TAP button - ideal for live situations.

USB functionality & data management

A USB port allows you to save your shows to a USB stick (FAT32), which is also included in the scope of delivery. You can also connect the device to your PC via USB and carry out firmware updates - for maximum future-proofing.

Robust housing - flexible use

The lighting console can be used either as a desktop device or in a 19" rack (6 U). The sturdy design and clear user interface with LCD display make the DMX Commander 512 an ideal control device for events of all kinds - from mobile DJs to permanent theater operations.

Conclusion: Versatile DMX console for professional lighting control

The EUROLITE DMX Commander 512 impresses with its simple operation, high flexibility and extensive connection options. Ideal for anyone looking for a reliable and modern lighting controller with a large number of channels and a clever user interface.

Features:

• 512 DMX channels
• 57 scenes/chases with 767 cues can be stored on 9 pages
• Intuitive operation with status LEDs and LCD display
• Total dimming, fade time and runtime adjustable
• Manual, time-controlled or music-controlled chase playback (microphone or jack)
• Multiple scenes and chases can be played simultaneously
• USB port for show storage & firmware update
• 2x USB type A ports for memory sticks (FAT32)
• PC connection via USB
• 19" rack installation (6 U) or table-top console housing
• Colored fader caps for free design (64 pieces included)

Technical data

• Power supply: 100-240 V AC, 50/60 Hz
• Total connected load: 2 W
• Power connection: P-Con (blue), incl. mains cable
• DMX outputs:
  • 1x 3-pin XLR (female)
  • 1x 5-pin XLR (female)
• Control via:
  • Music control via microphone
  • Music control via 6.3 mm jack socket (stereo)
• Suitable storage media: USB devices (FAT32)
• Display type: LCD
• Color: Black
• Dimensions (L x W x H): 48.3 x 26.6 x 8 cm
• Weight: 4.70 kg
• Housing type: Desktop desk / 19" rack mounting (6 U)
• Noise classification: Class 0 (noiseless)

Scope of delivery:

• 1x EUROLITE DMX Commander 512
• 1x mains cable (earthing contact)
• 1x USB stick
• 64x colored fader caps
• 1x instruction manual
