EUROLITE FD-36+1 DMX Dimmer Panel

EUROLITE FD-36+1 DMX Dimmer Panel

Intuitive lighting control made easy - the EUROLITE FD-36+1 DMX Dimmer Panel

The EUROLITE FD-36+1 DMX Dimmer Panel is the ideal solution for anyone who needs simple, fast and reliable control of DMX-capable lighting technology. Whether for smaller stages, mobile DJs, event technicians or permanent installations - with this compact and cleverly designed DMX controller, up to 36 DMX channels can be conveniently managed. Without complicated programming or complicated setup processes, the controller enables immediate commissioning - plug-and-play at a professional level.

Thanks to its robust desktop housing, intuitive channel structure and clear master fader, the FD-36+1 is particularly suitable for all applications that require simple operation and fast results. This means you are always in control of your light show - with precision and without distraction.

EUROLITE - Practical lighting technology for professionals and beginners

The EUROLITE brand has been known for decades for reliable lighting technology solutions that are firmly established in the professional event sector as well as in semi-professional use. With products such as the EUROLITE FD-36+1 DMX Dimmer Panel, the company consistently pursues the goal of combining powerful technology with simple operation. The focus is on functionality, quality and a fair price-performance ratio.

EUROLITE products are developed for everyday use - whether in clubs, stage productions, event spaces or rehearsal rooms. The FD-36+1 is a typical example of this philosophy: a controller that impresses with its robust design, simple configuration and flexible power supply.

Technical details of the EUROLITE FD-36+1 DMX dimmer panel

The EUROLITE FD-36+1 DMX Dimmer Panel offers direct control of up to 36 DMX channels. These are divided into three groups of 12 channels each, which are controlled via a total of 12 faders. The entire output power can be controlled via a central master fader - ideal for quick brightness adjustments or blackouts. Thanks to the clearly structured user interface, the panel is ideal for spontaneous lighting control without prior knowledge or programming steps.

The device has two 3-digit 7-segment LED displays that always provide information about the current channel or mode setting. DMX output is via an integrated 3-pin XLR socket, compatible with common DMX end devices such as spotlights, dimmers or light effect devices. The device also supports QuickDMX for compatible wireless solutions.

Another advantage is the flexible power supply: The panel can be powered either via USB-C (built-in version with included USB-A cable) or via a 9V block battery (not included). This makes the controller suitable for both stationary installations and mobile applications without a fixed power supply. Despite its extensive functionality, the energy consumption is less than 1 watt, which speaks for very high energy efficiency.

With a weight of just 1.55 kg and compact dimensions (34 x 14 x 6 cm), the FD-36+1 fits easily into any setup - whether on the lighting desk in a club, in the technology rack at an event or on a mobile DJ table. The black, matt lacquered metal housing emphasizes the professional look and reliably protects the electronics in tough everyday use.

For whom is the EUROLITE FD-36+1 the perfect solution?

The EUROLITE FD-36+1 DMX dimmer panel is aimed at anyone looking for an easy-to-use yet powerful control panel for DMX-controlled lighting technology. DJs, small event agencies, stage managers or venues without a fixed lighting console in particular benefit from the uncomplicated handling and rapid operational readiness of this controller.

Thanks to the minimalist operating concept, no training or lengthy familiarization is required - connect, control channels, enjoy the light. At the same time, the device offers a clear structure and control thanks to the grouping of channels. If you are looking for a reliable, portable and simply designed DMX controller, the FD-36+1 is the ideal tool.

The device also cuts an excellent figure as an addition to existing systems or as a backup solution in a touring case. Thanks to its compatibility with standard DMX and QuickDMX as well as its robust design, it is versatile and always ready for use.

Features:

• DMX controller for controlling up to 36 channels
• 12 faders in 3 channel groups for direct value adjustment
• 1 master fader for overall control
• Compatible with DMX512 and QuickDMX
• 3-pin XLR DMX output (built-in version)
• 2 x 3-digit 7-segment LED displays
• Black painted metal housing
• Compact desktop design (34 x 14 x 6 cm)
• Weight: 1.55 kg
• Power supply via USB-C (incl. cable) or 9V block battery
• Total connected load: < 1 W
• Protection class: IP20 (for indoor use)
• Simple plug-and-play without programming
