EV Electro Voice EVOLVE 50 White

The Evolve 50 PA system consists of 3 components with a total power of 1000W and a ClassD amplifier.

The system's 12" subwoofer features a 15mm plywood cabinet and a frequency response down to 37 Hz. The loudspeaker consists of eight 3.5" drivers and, together with the subwoofer, delivers up to 127 SPL.

Features:

• High-quality Bluetooth connection
• 120° horizontal, 40° vertical cover
• simple operation via LCD display
• ideal for transport
• 5 programmable presets
• Connections: 2x XLR/TRS Combo Jack Input, 1x 3.5 mm Input, 1x Stereo RCA Input, 1x Wireless Bluetooth® Audio Input, 1x XLR THRU Output, 1x XLR MIX OUT Outpu

Technical data:

• 1000W ClassD amplifier
• 12" subwoofer
• total weight: 31,3kg
• Subwoofer weight: 20,3kg
• Loudspeaker: 4,7kg
• Dimensions mm (HxWxD) Subwoofer: 530 x 345 x 471
• Dimensions mm (HxWxD) Loudspeaker: 825 x 102 x 172
• Dimensions mm (HxWxD) Tripod: 929 x 48.5 x 55

Specs:

• Power: 1000 W
• Housing Material: Plastic
• Pole Mount: no
• Woofer: 1 x 12
• Tweeter: none
• Set Offer: no
• Bluetooth: No
• Type: PA System
• Theme: PA and Sonication

Instruction manual / Safety instructions:

• Manual (2.48 MB)
