HK Audio Elements Smart Base Single

The Smart Base single system is incredibly flexible and easy to expand, making it the perfect PA solution for anything from clubs to open air gigs. For DJ applications where more bass is required, an E 110 SUB subwoofer will do the trick, while a second E 835 mid/high unit can be added for open air shows that require far-reaching mid/high frequencies.

Features:

• Elegant design
• Scalable and flexible to expand
• Practically cable-free
• Lightweight and compact
• Maximum output (with all add-ons): 2,400 watts
• Tweeter:
• Power-handling nominal (RMS): 300 W RMS @ 8 Ω
• Nominal impedance: 8 Ω
• Sensitivity 1W/1m: 100 dB (half space)
• Frequency response: -10 dB 140 Hz – 20 kHz, via active system
• Speaker: 8 x 3,5" broadband
• Directivity: 70° horizontal
• Crossover frequency: 140 Hz, 12 dB/oct.
• Connections: 1 x E-Connect-In; 1 x E-Connect-Out
• Dimensions: 11 x 74,5 x 12 cm (exkl. E-Connect- sleeves)
• Weight: 4,5 kg, 9.9 lbs
• Subwoofer:
• Model: E 110 Sub AS
• Headline: System Subwoofer
• Nominal impedance: 10 Ω
• Frequency response: -10 dB 45 Hz – 150 Hz (measured with active separation)
• Subwoofer amplifier: 1 x 600 W/Class-D @ 4 Ω
• Active protection circuits: RMS limiter, subsonic filter; DC, load, & thermal (temp.- controlled fan)
• LF Speaker: 1 x 10" (2" voice coil)
• Connections: 1 x XLR-Kombi-In, 1 x XLR-Through, 2 x Speakon-Out (1 x Sub + 1 x Mid-High), 2 x E-Connect-Out
• Input Sensitivity: (selectable) +4 dBu / -10 dBu
• Continous power into 4 ohms: 600 W Class-D @ 4 Ω (Subs) / 600 Watt Class-D @ 4 Ω (Mid/High)
• Pole mount: 2 x E-Connect
• Dimensions: 30 x 48 x 46 cm
• Weight 18,5 kg / 40,8 lb

Specs:

• Power: 600 W
• Housing Material: Plastic
• Pole Mount: yes
• Woofer: 1 x 10
• Tweeter: none
• Set Offer: no
• Bluetooth: No
• Type: PA System
• Theme: PA and Sonication

Instruction manual / Safety instructions:

• Manual (1.23 MB)
