Pioneer DJ VM-70

The VM-70 active produces clear audio with fast response and punchy bass. The 6.5 inch active monitor speaker can be adjusted to the acoustic conditions of the room and is therefore very suitable for creating a club sound, which is especially interesting for DJ-ing. The flat frequency response of the VM-70 also allows for a natural reproduction of the sound, which is why the VM-70 can also be perfectly integrated into a studio setup.

Features:

• Pioneer DJ VM-70
• Clear, low-distortion audio with fast bass response for authentic club sound
• Class-D amplifier with 96 kHz DSP for wide bandwidth audio reproduction
• 4mm thick aluminium front insert suppresses resonance, vibration and delivers sound that authentically reproduces the original source
• Aramid fibre woofer for superb punch
• Vortex bass accelerator for dense, vibration-free low end
• Powerful reproduction of mid- and high-frequency sounds dan Constant Directivity horn
• CD Horn and Woofer Edge are Specially Designed for Smooth Transfer of High-Frequency Sound to the Tweeter for a Natural Sound
• flat tuned
• 2 controls: Low EQ and High EQ with 4 different positions each
• 16 possible EQ settings
• hexagonal aluminium front panel for a fresh look and improved sound quality and durability
• Tweeter protection reduces the risk of damage to the high frequency cone
• Colour: Black

Specifications:

• Type: 2-way bi-amp active speaker.
• Tweeter: 1" (25 mm) SILK dome tweeter
• Woofer: 6.5" (165 mm) ARAMID cone
• Maximum Sound Pressure: 112 dB
• Amplifier output power: Class D with 96 kHz DSP; Bass: 70 W / 4 Ω; Treble: 30 W / 4 Ω
• Frequency Range: 437 Hz - 36 kHz
• Impedance: 10 kΩ
• High EQ: 4 selective EQs
• Low EQ: 4 selective EQs
• Cross Over Frequency: 3 kHz
• Power Supply: AC 100-240 V, 50 Hz / 60Hz
• Enclosure: Bass reflex
• Cabinet material: MDF vinyl laminate
• Bass reflex baffle: HIPS with 4 mm aluminium plate
• Inputs: 1 x XLR/jack combo x 1 (balanced); 1 x Cinch (unbalanced)
• Contents: VM-70 x 1 (only available separately); power cord x 1; 1 x floor protection pads (4 pieces on 1 carrier foil); safety instructions; user manual
• Dimensions(HxWxD): 341 x 229 x 312 mm

Specs:

• Color: Black
• Woofer: 1 x 6,5
• Frequency Range from: 37 Hz
• Frequency Range to: 36000 Hz
• Set Offer: no
• Number of paths: 2-way
• Type: Studio Monitor
• Theme: Recording and Studio

Instruction manual / Safety instructions:

• Manual (625.51 KB)
