RME FireFace UFX III

The RME FireFace UFX III is a 188-channel, 24-bit/192kHz high-end USB 3 audio interface and the successor of the FireFace UFX+.

The FireFace UFX III is the center of any multitrack studio and can handle up to 94 channels of I/O with ease. Its unprecedented flexibility, compatibility, DURec (Direct USB Recording) integration and RME's famous low-latency hardware and driver design guarantee flawless operation in any mode and application.

Equipped with professional features like SteadyClock FS, MADI I/O (64 channels), a powerful DSP, USB 3. 0 (full 94 channels I/O Class Compliant ready), TotalMix FX, Direct USB Recording and support for the separately available Advanced Remote Control USB make the RME FireFace UFX III the preferred professional tool for multitrack recording, mixing and mastering.

Features:

• 12 x Analog I/O
• 4 x Mic/Line Input
• 2 x XLR Out
• 2 x Phones Output
• 1 x AES I/O
• 2 x SPDIF I/O
• 2 x ADAT I/O
• 1 x Word Clock I/O
• 1 x MADI I/O
• 2 x MIDI I/O
• 2x MIDI over MADI
• USB 3.0 / USB 2.0 compatible
• Power supply: Internal switching power supply, 100 - 240 V AC, 36 Watt
• Dimensions with rack ears (WxHxD): 483 x 44 x 210 mm
• Dimensions without rack ears (WxHxD): 440 x 44 x 210 mm
• Total depth: 240 mm
• Weight: 2.8 kg

Specs:

• Color: Grey
• Rack Mountable: yes
• Line Inputs: 12
• Line Outputs: 8
• Mic Inputs: 4
• Phono Inputs: 0
• Instrument Inputs: 4
• digital Output: ADAT / AES/EBU / S/PDIF
• digital Input: ADAT / AES/EBU / S/PDIF
• Headphone Out: yes
• MIDI Inputs: 2 Ports
• MIDI Outputs: 2 Ports
• Host Port: USB
• Number of headphone outputs: 2
• Type: Audio Interface
• Theme: Recording and Studio

Instruction manual / Safety instructions:

• Manual (2.55 MB)
