Sennheiser AC41-EU Antennen Combinder

The Sennheiser AC41-EU active antenna combiner is compatible with the evolution wireless G3 and G4 systems. The AC 41 operates up to four ew series stereo transmitters with a common antenna. The power supply of the SR IEM G4 transmitters is provided by the NT 3-1 power supply unit (supplied with the SR IEM G4) via the BNC cables, making the use of additional power supplies obsolete.

Features:

• Use up to 4 wireless stereo transmitters with one antenna
• Power supply of the SR IEM G4 transmitter from the power supply unit via the BNC cable, no further power supplies required
• Compatible with G3 and G4 systems

Technical Specificatons:

• Frequency range: 470 - 608 MHz, 470 - 870 MHz
• Impedance: 50 Ω
• Dimensions: approx. 212 x 168 x 43 mm
• Weight: approx. 1470 g
• Power consumption: max. 3.4 A (with connected transmitters)
• Temperature range (storage): -20 °C to +70 °C (-4 °F to 158 °F)
• Temperature range (operation): -10 °C to +55 °C (14 °F to 131 °F)
• Power supply: 13.8 V DC (with tabletop power supply unit NT 3-1); 11.4 V DC (protected against reverse supply), 350 mA
• HF input: max. 30 mW per input
• Pass-through attenuation: 0 dB (±1 dB)
• Relative humidity Operation: 5 to 95 %

Scope of delivery:

• 1x Active antenna combiner (470-870 MHz EU & UK / 470 - 608 MHz US)
• 1x NT 3-1 power supply with one EU, UK, US adapter each
• 4x BNC antenna cable

Specs:

• Type: Accessories
• Theme: Microphones
