Showtec Spectral M800 Q4 IP65

The Showtec Spectral M800 is probably one of the best known spots in the Showtec range. These robust and reliable spotlights are used at almost all light shows at all events or festivals in Europe. The new Spectral M800 Q4 IP65 has now become a true RGBW spotlight. This not only extended the entire colour spectrum, but also increased the light output by 30%. The integrated virtual color wheel with the most frequently used colors can be controlled manually or run in auto mode. The spotlight is made of cast aluminium and contains 14 RGBW LEDs for excellent colour mixing without any RGB shading on nearby surfaces. The housing is fully IP65 rated and the XLR connectors and Seetronic power connections allow reliable outdoor operation even in the harshest weather conditions. With this redesigned spotlight, the Spectral Series once again lives up to its reputation as one of the most popular and reliable industry standards for professional lighting engineers.

Features:

• 16-bit dimmer
• Robust housing
• No fans, low noise
• RDM
• RGBW color mixing

Technical data:

• Output power:
• Max. Flux: 12000 lm
• Max. Intensity: 15294 cd
• Light source:
• Number of LEDs: 14 x RGBW
• Drive current: 350 mA
• Color range: 16.7 million additive RGBW colors
• with full saturation control
• Electric:
• Input voltage: AC 100 V~240 V, 50/60 Hz
• Max. Power rating: 65 W
• Control:
• Included: Display for auto mode and individual control
• Control protocol: DMX512
• Control variant: Tour, TR16, ARC1, AR1.d, AR1.S, HSV
• Optics: dimmer: 0-100%
• Stroboscope: 0-20 Hz
• Optics: 16°.
• Physically:
• Dimensions: 180 x 235 x 320 mm
• Weight: 4,8 kg (indoor)/ 5,2 kg (outdoor)
• Housing: die-cast aluminium
• Color: Black
• Connections: XLR (3 & 5 pin) DMX input/output,
• Powercon mains input / output
• Cooling: Forced convection cooling
• Operating temperature: -40°C ~45°C (in operation) / -20°C ~45°C (switch on)

Specs:

• IP Classes: IP65
• Type: PAR Spotlight
• Theme: Light and Show

Instruction manual / Safety instructions:

• Manual (2.5 MB)
