Studiomaster Digilive 8C

The Studiomaster DigiLive 8C offers a powerful platform and a wealth of professional features, all in a single ultra-compact mixer. Flexible connectivity with an intuitive user interface allows you to mix with confidence, right from the front panel. In addition, you can choose from three modes of operation to customize the application to your needs. Furthermore, with a 40-bit floating-point DSP and SHARC processor, you can take advantage of powerful processing to shape your sound to perfection.

Features:

• Extremely compact
• 8 inputs, 6 mic, 1 stereo
• Connect to any device with Wi-Fi or LAN
• PHONE - TABLET - LAPTOP - Multiplatform
• 4 effect busses
• Assignable footswitch input
• Full control from the front panel
• Analog feel in operation
• Balanced input and output jacks
• Professional features throughout

Specifications:

• Inputs: 8 analog inputs
• MIC input: 6 MIC/LINE COMBI XLR/TRS
• LINE input: 1 STEREO jack/3.5 mm mini jack
• Master output: 2 left/right balanced XLRs
• Internal busses: 4 stereo FX / 2 mono AUX / stereo PFL / main mix
• Stereo Monitor: 2 TRS jack outputs
• Headphones: 1 TRS jack output
• Control interface: full mix of 3 rotary encoders
• Sampling frequency: 48 KHz
• AD/DA: 48 KHz, 24-bit
• DSP: 40-bit floating point, SHARC processor
• Remote control: cross-platform - any device with Wi-Fi / Lan and web browser
• Effects: 4 - programmable DELAY x2 and REVERB x2
• USB interface: 2 for playback/recording, scene storage and system updates
• Network: external WIFI module or RJ45 LAN connection
• Power supply: 90-240V ~ 50/60Hz power supply 12VDC output
• Weight: 8kg

Specs:

• Type: Mixer
• Theme: PA and Sonication
