Tascam US-4x4HR

Features:

• USB audio/MIDI interface (4 inputs, 4 outputs)
• Usable with Windows, Mac, iOS, iPadOS
• Sampling rates up to 192 kHz / 24 bit
• Inputs: 2 × XLR/jack (balanced) for microphone/line-/instrument levels, 48 V phantom power, inputs can be individually switched on/off via software
• Outputs: 2 × jack socket (balanced), configurable via software
• Direct monitoring function with low latency
• MIDI input/output
• 6.3 mm headphone output (18 mW per channel)
• Separate level controls for line and headphone output
• Loopback function for live streaming etc., input and computer signals each switchable mono/stereo, OBS compatible
• Windows buffer size selectable from four samples
• Power supply via USB (for iPhone/iPad an additional power supply is required)
• Switchable power saving function
• Update notification for driver/firmware
• Robust aluminium housing with bevelled shape for easy operation
• Includes Cubase LE, Cubasis LE3, IK Multimedia SampleTank 4 SE, Antares Auto-Tune Unlimited (3 months free use)
• Maximum input level (Mic/Line/Inst): +10 dBu / +20 dBu / +10 dBV
• Maximum input gain: 56 dB
• Maximum output level: +20 dBu
• Equivalent input noise of the microphone preamplifiers: -128 dBu
• Signal-to-noise ratio: 108 dB / 110 dB
• Distortion (THD+N, microphone input to computer): 0.0013%.
• Crosstalk attenuation: ≥ 95 dB
• Power supply: USB / DC 5 V, 700 mA
• Power consumption: 1,75 W
• Overall dimensions (W × H × D): 186 mm × 65 mm × 160 mm
• Weight: 1,1 kg

Specs:

• Color: Black
• Rack Mountable: no
• Line Inputs: 4
• Line Outputs: 4
• Mic Inputs: 4
• Phono Inputs: 0
• Instrument Inputs: 4
• digital Output: none
• digital Input: none
• Headphone Out: yes
• MIDI Inputs: 1 Port
• MIDI Outputs: 1 Port
• Host Port: USB
• Number of headphone outputs: 2
• Type: Audio Interface
• Theme: Recording and Studio
