ALTO TrueMix 600

The Alto Professional TrueMix 600 is a portable audio mixer with Bluetooth and built-in USB stereo audio interface that provides all the essential features you need for home recording, livestreaming, podcasting, or performing. The TrueMix 600 has a dedicated Bluetooth channel for easy streaming from your personal devices. The Bluetooth channel also supports feedback-free phone pairing through Mix-Minus technology, a feature that no other audio mixer series in this class supports. There are six analog inputs with high-headroom circuitry for minimal noise and clipping in your signal. The microphone input channels offer XLR inputs that are great for connecting dynamic or condenser microphones with 48V phantom power. These channels also feature balanced ¼" line inputs for connecting instruments and other line-level signals. There are also two stereo input channels, each with two balanced ¼" TRS inputs. These inputs are perfect for your line-level audio sources. All channels feature dual-band EQ with color-coded controls that allow you to adjust for the perfect sound, even in low-light conditions. Connecting the TrueMix 600 to your computer is also lightning fast, with plug-and-play connectivity on Windows and macOS. The TrueMix 600 is a compact, feature-packed audio mixer that's perfect for use on the go.

Robust output routing

Whether you're making music at home, recording a podcast, or live streaming online, it's important to be able to hear yourself. The TrueMix 600 has a variety of output and routing options to cover every scenario. There are two headphone outputs, each with its own independent volume control. If you want to route your audio to another destination, such as an external effects processor, there's an AUX send/return and individual AUX send controls for each channel, so you can always choose the perfect mix. For recording, the USB output sends a copy of the main outputs to your computer, or you can connect the 2-track input/output to an external recorder, which can also be sent directly to one of the headphone outputs. The TrueMix 600 provides everything you need to have full control over your audio routing.

Features:

• ALTO - TrueMix 600
• USB I/O for audio playback and stereo recording
• 1/4" main, tape and headphone outputs
• Microphone input channel with 18 V phantom power and balanced line input
• Two stereo input channels with 1/4" TRS balanced jacks
• Two-band EQ on all channels
• 2-track inputs with assignable routing: main mix or headphone output
• Frequency response: 20 Hz - 22 kHz
• THD+N (Total Harmonic Distortion): All inputs: < 0.005% (@ 4 dBu, 1 kHz)
• Gain range: microphone inputs (channels 1-2): 0 - 50 dB, line inputs (channels 1-2): 15 dBu - 35 dBu, line inputs (channels 3-6): -20 dBu - +20 dBu
• Maximum voltage gain: 70 dB (MIC INPUT to MAIN MIX OUTPUT), 80 dB (MIC INPUT to CTRL ROOM / PHONES OUPTUT), 60 dB (MIC INPUT to AUX SEND)
• SNR (Signal to Noise Ratio): All inputs: > 110 dBu
• Crossover frequency: Adjacent inputs: < -80 dB @ 1 kHz# Inputs to outputs: < -75 dB @ 1 kHz (stereo L/R, channels 1-2, hard left or right biased).
• Phantom power: +45 ~ +49V with switch control
• Impedance: Microphone inputs: 3.9 kΩ, All other inputs: > 10 kΩ, Aux outputs: 1 kΩ, All outputs: 120 Ω
• Equalization: High: ±15 dB @ 12 kHz# Low: ±15 dB @ 80 Hz
• Bluetooth: Profile: A2DP, Module: Bluetooth 5.0, Operating frequency: 2402 MHz - 2480 MHz, Range: 100 ft. / 30.5 m
• Connectors: (5) 6.35 mm (1/4") TRS outputs, (6) 6.35 mm (1/4") TRS stereo L/R inputs, (2) 6.35 mm (1/4") TRS headphone outputs, (2) 6.35 mm (1/4") TRS mono inputs, (1) standard RCA L/R input, (1) standard RCA L/R output, (2) XLR inputs, (1) USB type-B input, (1) DC input
• Controls: (1) power switch, (10) volume controls (1 per input, 1 aux return, 1 2TK in, 2 headphone outputs, 1 Bluetooth, 1 main out), (4) stereo pan controls (1 per input), (4) aux volume controls (1 per input), (4) EQ Low knobs (1 per input), (4) EQ Hi knobs (1 per input), (4) Gain knobs (1 per input), (3) Lock switches (2 source select, 1 Bluetooth), (1) Horizontal slide switch
• Indicators: (1) power LED, (4) peak LEDs; (1) phantom LED, (16) main out meter LEDs, (1) Bluetooth LED
• Power supply: Connector: DC, Voltage: 18V, 1A, Consumption: 18W
• Dimensions: (width x depth x height): 225.5 x 217 x 74 mm
• Weight: 1.4 kg

Specs:

• Type: Mixer
• Theme: PA and Sonication
