Boss IR-2 Amp & IR Cabinet

The IR-2 packs the inspiring sounds of classic tube amps and mic'd speaker cabinets into a standard floor pedal. Experience studio-quality sounds anywhere - on quiet stages, on the road, during live recordings and in the rehearsal room. Thanks to BOSS' decades of experience, each variant delivers the same richness of nuance and dynamic response as a real amplifier on a real speaker cabinet. In addition, the combination of modern DSP, 32-bit floating point processing and 96 kHz sampling rate ensures first-class audio quality.

With a total of eleven amp types, the IR-2 covers every amp sound - from famous tube combos to vintage or modern stacks. Several famous BOSS amps are also available, including a high-gain Brown type from the Katana series. All amplifiers are combined with high-quality Celestion Digital IRs, which can be used to create first-class sounds straight away. If you want to use your own speaker impulse responses, you can load them into the pedal via USB-C and specific software.

Thanks to the IR-2's intuitive user interface, you can set up your sound in no time at all. Simply select an amplifier type and edit the sound using the familiar controls just like on an amplifier. You can use the Ambience control to add a little more spaciousness and depth if required. As with a conventional amplifier, you can connect your other pedals to the input of the IR-2. You can also use the send/return loop to integrate modulation, delay and reverb effects into the signal chain after the amplifier. The TRS return input supports stereo operation to play stereo effects via the audio outputs of the IR-2.

Features:

• High-quality amplifier emulator and cabinet IR loader in BOSS compact pedal format
• First-class audio quality thanks to 32-bit floating point processing and 96 kHz sampling rate
• Eleven amplifier types and high-quality speaker impulse responses from Celestion Digital
• Simple operation with controls for level, gain, bass, mids and treble
• Ambience effect with its own control
• Mono input and stereo outputs
• Mono/stereo loop for integrating modulation effects, delay or reverb behind the amplifier emulation
• Headphone connection for practicing
• USB-C for recording and audio playback via computer or mobile device*
• Switch between two amp/speaker sounds using the pedal switch or an external footswitch
• Special IR-2 IR Loader software (macOS/Windows) for loading your own speaker impulse responses
• Amplifier and speaker section can be switched on/off individually

Technical data

• Sampling frequency: 96 kHz
• AD conversion: 24 bit + AF process
• DA conversion: 32 bits
• Processing: 32-bit floating point
• IR cabinet data format: Mono, maximum 500 ms, 44.1/48/96 kHz, 16-bit linear/24-bit linear/32-bit floating point
• Preset IR cabinet: 11
• User IR cabinet slot: 11
• Nominal input level: INPUT, RETURN: -20 dBu
• Maximum input level: INPUT, RETURN: +7 dBu
• Input impedance: INPUT, RETURN: 1 MΩ
• Nominal output level: OUTPUT A (MONO), OUTPUT B, SEND, PHONES: -20 dBu
• Maximum output level: OUTPUT A (MONO), OUTPUT B, SEND, PHONES: +7 dBu
• Output impedance: OUTPUT A (MONO), OUTPUT B, SEND: 1 kΩ, PHONES: 44 Ω
• Recommended load impedance: OUTPUT A (MONO), OUTPUT B, SEND: 10 kΩ or more, PHONES: 44 Ω or more
• Bypass: Buffered bypass
• Controls: Type knob, GAIN knob, TREBLE knob, LEVEL knob, MIDDLE knob, AMBIENCE knob, BASS knob, pedal switch
• Display: CHECK display (used to display the channel and to check the battery)
• Connections: INPUT jack, OUTPUT A (MONO) jack, OUTPUT B jack, SEND jack: 1/4-inch TRS jack, RETURN jack: 1/4-inch TRS jack plug, CH SEL jack: 1/4-inch TRS jack plug, DC IN jack, PHONES jack:
• Stereo miniature jack plug, USB port: USB Type-C(R)
• Power supply: Alkaline battery (9 V, 6LR61 or 6LF22, commercially available), mains adapter (PSA series: sold separately)
• Current consumption: 160 mA
• Expected battery life in continuous operation: Alkaline: approx. 3.5 hours (6LR61)
• Accessories: Instruction sheet ("SAFE USE OF THE DEVICE", "IMPORTANT NOTES" and "Information"), dry cell battery (9 V, 6LR61 or 6LF22)
• Width: 73 mm
• Depth: 129 mm
• Height: 59 mm
• Weight (including battery): 450 g

Specs:

• Impedance: 1 Ω
• Channels: 1
• Effect Processor: yes
• Amplification: Modulation
• Headphone Out: yes
• digital modelling: yes
• Type: Amps
• Theme: Guitars and Basses
