Monacor MDSP-24

Features:

• AD/DA converter, 24 bits
• Sampling rate: 48 kHz
• 2 RCA inputs (0.9 V/2 V, switchable)
• 4 RCA outputs (0.9 V)
• Programming and administration via mini USB interface and controlling software (Windows* XP/Vista/7, Mac OS X Intel)
• The control software allows to adjust the following parameters (supplied with promotional code): Filters: high-shelf, low-shelf, high-pass, low-pass; Graphic equalizer; Parametric equalizer; Matrix mixer; Volume, mute, polarity
• Power supply via USB interface or via optional power supply DC 4.5-24 V
• Dimensions: 107 x 30 x 96 mm
• Weight: 155 g

Technical Specificatons:

• Type: digital signal processor (DSP)
• Input signal: 0.9 V/2 V
• Output signal: 0.9 V
• High-pass filter: software
• Admiss. ambient temp.: 0-40 °C
• Power supply: USB or DC 4.5-24 V via optional power supply
• Dimensions: 107 x 30 x 96 mm
• Weight: 155 g
• Inputs: 2 x RCA
• Outputs: 4 x RCA
• Other features: mini USB interface
