Palmer Macht 402

The Palmer MACHT 402 is a stereo power amp, especially for guitars. It can be switched practically in front of any guitar box.The amplifier with class D amplifiers has a quiet fan and all essential protection circuits.

Due to the special development of the circuit, the amplifier is tailored for guitar signals and allows for the true enjoyment of a tube end stage.

The MACHT 402 Rumpelfilter, LED displays, a 3-way selector switch for input sensitivity, limiter and a ground lift. With XLR and 1/4 "inputs, Speakon compatible and 1/4" output connectors, the Palmer MACHT 402 is the perfect high-performance center for guitar preamps, small amplifiers, modellers and even effects pedals.

Features:

• Product type: Power stage
• Type: 2-channel
• Output power (1 kHz 4 ohms): 2 x 200W
• Output power (1 kHz 4 ohms): 2 x 200W
• Output power (1 kHz 8 ohms, bridge mode): 400W
• Circuit design: Class D
• Frequency response: 20 - 20000Hz
• THD: <0.1%
• Voltage gain (gain): 32 dB / 26 dB / 28 dBdB
• Input Sensitivity: 0.68V / 1.4V / 1.2V
• Protection circuits: overvoltage, overheating, short circuit, soft start, direct current
• Controls: On / Off, Volume, High, Low, Mode (bridge / parallel / stereo), Ground Lift, Limiter, Sensitivity
• Indicators: Clip, Protect, Power, Mode (bridge / parallel), signal
• Line inputs: 2
• Line input connectors: 6.3 mm jack, RCA
• Speaker Outputs: 2
• Speaker Output Connectors: Speakon compatible, 6.3 mm jack
• Cooling: silent fan
• Power supply: switching power supply
• Power consumption (at full load): 470W
• Operating voltage: 115 V AC / 230 V AC (switchable)
• Measurements: Width: 482mm x Height: 44mm x Depth: 244mm (19 inches / 1U)
• Weight: 3.8 kg

• 3-way selector for input sensitivity
• Rumpfilter

Specs:

• Impedance: 4 Ω
• Impedance: 8 Ω
• Channels: 2
• Effect Processor: no
• Power: 200 W
• Amplification: Solid State
• Amp Type: E-Guitar Head
• Headphone Out: no
• digital modelling: no
• Type: Amps
• Theme: Guitars and Basses

Instruction manual / Safety instructions:

• Manual (1.21 MB)
