PreSonus Quantum 2626

Features:

• 26x26 Thunderbolt 3 ultra-low-latency audio interface
• <1 ms roundtrip latency; record direct to DAW with your favorite plug-ins engaged
• 24-Bit/192kHz Operation with high-quality 115 dB A/D/A converters
• Studio One Artist and Studio Magic plug-in bundle included
• Simultaneous I/O up to 26 inputs / 26 outputs (at 44.1 or 48 kHz)
• 8 pristine XMAX preamps
• 2 Instrument Inputs
• 8 balanced line inputs
• Dual headphone outputs with independent level control
• Balanced stereo main outputs with independent level control
• 8 DC Coupled balanced line outputs
• 2 preamp direct outputs with returns to insert outboard gear
• Main Output Level Control
• Balanced Stereo Main Output (TRS)
• Eight Balanced Line Outputs (TRS (outs 1 & 2 share a DAC with the main output))
• Two Preamp Outputs (channels 1 & 2)
• Two Line Returns (channels 1 & 2)
• ADAT Optical/Dual SMUX inputs/outputs: 16x16 channels at 44.1 or 48 kHz; 8x8 channels at 88.2 or 96 kHz
• Stereo S/PDIF coaxial input and output
• Thunderbolt 3 high-speed bus
• 24-bit resolution and up to 192 kHz sampling rate
• BNC word clock input and output with low-jitter clocking
• MIDI I/O
• Road-rugged construction with all-metal chassis and metal knobs
• 1U rack-mountable
• 12 VDC external power supply (included)
• Height: 44,45 mm
• Depth: 177,8 mm
• Width: 482,6 mm
• Weight: 2,72 kg

Specs:

• Color: Black
• Rack Mountable: yes
• Line Inputs: 8
• Line Outputs: 8
• Mic Inputs: 8
• Phono Inputs: 0
• Instrument Inputs: 2
• digital Output: ADAT / S/PDIF
• digital Input: ADAT / S/PDIF
• Headphone Out: yes
• MIDI Inputs: 1 Port
• MIDI Outputs: 1 Port
• Host Port: Thunderbolt
• Number of headphone outputs: 2
• Type: Audio Interface
• Theme: Recording and Studio

Instruction manual / Safety instructions:

• Manual (8.82 MB)
