Universal Audio Apollo X8 Gen 2 Studio+

Universal Audio Apollo X8 Gen 2 Studio+: Professional Thunderbolt 3 audio interface

The Universal Audio Apollo X8 Gen 2 Studio+ is an advanced audio interface that has been specially developed for professional requirements. It combines first-class sound quality, state-of-the-art technologies and flexible connectivity options in an elegant design. With its 18 input and 24 output channels, it is perfect for studio recording, mixing and post-production in surround formats up to 7.1.

Universal Audio: synonymous with quality and innovation

Universal Audio stands for high-quality audio solutions and is an integral part of renowned studios worldwide. The Apollo series combines the tradition of analog sound with the precision of modern digital technology. The Apollo X8 Gen 2 Studio+ continues this tradition and offers you the tools you need for professional results.

Technical highlights of the Apollo X8 Gen 2 Studio+

With 24-bit/192 kHz conversion and a powerful 6-core SHARC DSP processor, the Apollo X8 Gen 2 Studio+ is perfectly suited for real-time processing and the use of UAD plug-ins. The four Unison microphone preamps offer the possibility to emulate the sound of classic analog preamps in detail. Functions such as auto-gain, +48 V phantom power, pad, low-cut and phase reverse make studio work easier.

For demanding audio productions, the interface supports surround formats up to 7.1 with speaker calibration and downmix. Dual Crystal Clocking technology ensures jitter-free recordings with stable stereo imaging. Thanks to the cascadability of up to four Apollo devices and compatibility with Mac and Windows, the interface is extremely flexible to use.

Studio+ Plugin Bundle: Extended possibilities

The Studio+ Plugin Bundle, which offers a selection of high-quality UAD plug-ins, is included in the scope of delivery. These emulate classic studio hardware such as compressors, equalizers and reverbs and significantly expand the creative possibilities. Thanks to real-time processing by the integrated DSP processor, the plug-ins can be used without delay.

Recommended purchase: Universal Audio Apollo X8 Gen 2 Studio+

The Universal Audio Apollo X8 Gen 2 Studio+ is the perfect choice for professional sound engineers, producers and musicians who need a powerful and versatile audio interface. With its exceptional sound quality, extensive functions and support for surround formats, it meets the highest demands. This interface is an investment in outstanding results and a future-proof studio environment.

Features:

• 24-bit / 192 kHz AD/DA conversion
• 6-core SHARC DSP for internal UAD real-time processing
• 4 Unison microphone preamps
• Auto-gain function
• +48 V phantom power
• Pad, low-cut and phase reverse
• Switch for monitor switching
• Dim or mono assignable function button
• LED meter
• Integrated talkback microphone
• Support for surround formats up to 7.1 with speaker calibration and downmix
• Dual Crystal Clocking for jitter-free and artifact-free recordings
• Studio+ plug-in bundle for Mac/Windows
• Cascadable with up to 4 Apollos via Thunderbolt
• Design: 19" / 1 U
• Dimensions: 483 x 308 x 44 mm
• Incl. external power supply
• 4 microphone inputs (XLR)
• 2 Hi-Z inputs (6.3 mm jack)
• 8 line inputs (6.3 mm jack)
• 2 monitor outputs (6.3 mm jack)
• 8 line outputs (6.3 mm jack)
• S/PDIF input and output (coaxial)
• 2 ADAT inputs and outputs
• BNC word clock input and output
• 2 stereo headphone outputs (6.3 mm jack)
• Thunderbolt 3 connection, compatible with Thunderbolt 2 (adapter optional)
• Maximum sampling rate: 192 kHz
• Maximum resolution: 24 bit
• Bus-powered: No
• Compatible with Windows and Mac OS

Specs:

• Color: Silver
• Rack Mountable: yes
• Line Inputs: 8
• Line Outputs: 8
• Mic Inputs: 4
• Phono Inputs: 0
• Instrument Inputs: 2
• digital Output: ADAT / S/PDIF
• digital Input: ADAT / S/PDIF
• Headphone Out: yes
• MIDI Inputs: 0 Ports
• MIDI Outputs: 0 Ports
• Host Port: Thunderbolt
• Number of headphone outputs: 2
• Type: Audio Interface
• Theme: Recording and Studio
