NEW Union Audio ELARA.6 professioneller 4+2-Kanal Performance-DJ-Mixer

Union Audio ELARA.6 professional 4+2-channel performance DJ mixer

The Union Audio ELARA.6 is an uncompromising premium DJ and live mixer for professional applications in clubs and studios. With four dual main channels, two additional return channels and an innovative Analogue Processing (AP) system, it offers maximum sound control, creative freedom and audiophile quality - handmade in the UK.

4+2 channels with precise 4-band tone control

Each of the four main channels has dual inputs (phono/line) and a comprehensively tuned 4-band EQ with dual mids. Two additional mic/stereo returns expand the setup to include further sound sources - including their own 4-band tone control with semi-parametric mids, additional aux send and their own dual cue system.

Analog processing - creative sound performance

On both sides of the main channels are the powerful AP channel strips with:

• Switchable high/low-pass filter with resonance and frequency control
• Drive control with active side-chain - from subtle warmth to dark distortion
• Width control for infinitely variable control of the stereo image (mono to extra-wide)

In addition, the signal of each channel strip can be routed to Aux 1 either pre- or post-AP - ideal for complex effects chains and creative transitions.

Dual Cue & flexible effect integration

With dual cue per channel, the ELARA.6 is perfect for back-to-back sets or quick artist changes. Two aux sends per channel enable flexible effect paths, including for the mic/stereo returns. The returns can also be assigned to the channel strip or the crossfader - for maximum creative options.

Rotary or linear - instantly customizable

Thanks to interchangeable fader plates, the ELARA.6 can be switched between rotary and linear fader configuration in less than a minute. The integrated Innofader crossfader has adjustable curve and can be deactivated if required.

Professional connectivity & audiophile performance

With balanced XLR master out (+27 dBu), separate booth out, record out and two headphone connections (6.3 mm & 3.5 mm), the ELARA.6 is equipped for any professional environment. A dynamic range of over 114 dB and a frequency response of 10 Hz - 50 kHz guarantee uncompromising sound fidelity.

Conclusion: High-end performance for creative DJs

The Union Audio ELARA.6 combines classic analog warmth with innovative performance functions. For DJs looking for uncompromising audio quality, maximum creative control and the highest build quality, it is the perfect tool for clubs, studios and demanding live sets.

Features:

• 4+2-channel performance DJ mixer
• Dual inputs (phono/line) per channel
• 4-band EQ with double mids
• 2 aux sends per channel
• Dual cue per channel
• Analog processing with filter, drive & width control
• Pre/Post-AP routing on Aux 1
• Mic/stereo returns with 4-band EQ & dual cue
• Switchable between rotary and linear faders
• Innofader crossfader (adjustable & deactivatable)
• Pre/post-EQ monitoring, split cue & cue/mix
• Master-Out: 2 × XLR balanced (+27 dBu)
• Booth-Out: 2 × 6.3 mm jack
• Record-Out: 2 × Cinch (RCA)
• Headphones: 6.3 mm & 3.5 mm
• Internal universal switching power supply (can be used worldwide)
• Made in UK
• Frequency response: 10 Hz - 50 kHz (+0 / -1 dB)
• Dynamic range: >114 dB
• THD+N: 0.03 %
• Channel crosstalk: < -100 dB
• Max. Output level: +27 dBu balanced
• Power consumption: max. 40 W

• Dimensions & weight:
• Dimensions (W × D × H): 30.0 × 37.0 × 8.0 cm
• Weight: 5.3 kg

Specs:

• Channels: 6
• Rack Mountable: no
• Effect Processor: no
• Talkover: no
• USB Port: no
• Line Inputs: 4
• Mic Inputs: 2
• Phono Inputs: 4
• Crossfader adjustable: yes
• Color: Black
• Type: DJ Mixer
• Theme: DJ Equipment
