Allen & Heath GL 3800 -832B
We are no longer offering this product.
You will surely find a current product that meets your needs, because we are striving to expand our extensive product range.
- more of Allen & Heath
Allen & Heath GL 3800 -832B Product Details
Features:
- 24, 32, 40, and 48 channel frames
- A,B,C,D mono/stereo channel options
- LR and M mix buses
- 8 Audio groups with pan and routing to LR and M
- 10 Auxes including a dedicated stereo send
- 2 full stereo channels each with mic and stereo line inputs
- 2 extra dual stereos provide 4 summed or independent stereo returns
- Fully featured 12x4 Matrix
- Proper dual functionality for FOH/Monitor mixing
- Recording capable with channel direct outputs
- M can be used for LR mono sum, engineers wedge, or centre/sub mix
- Matrix external inputs with level trims and common input capability
- Stereo channel mic inputs can cross patch into matrix for ambience feed
- Responsive 4 band, 2 sweep EQ
- 100Hz channel high pass filters
- Individual phantom power and polarity switching
- Integral meterpod with 11 LED-illuminated, moving coil VU meters
- Wide angle LED channel and master meters
- Dedicated stereo monitor meters
- Per channel pre/post fader aux switching for full flexibility
- Recessed pre/post-EQ aux switching per channel
- Internal jumper plugs for aux, direct out and other options
- Mutes on all fader masters
- 100mm premium grade dual rail faders
- Assignable talkback to all outputs
- 1kHz oscillator / pink noise generator with external output
- 2-track monitoring and replay to LR
- 3 headphones/earpiece sockets and local monitor outputs
- Electronically balanced XLR outputs with +26dBu drive capability
- Preamp 74dB range with +34dBu input capability for mic or line
- Ultra low noise mix head amp design
- Uses external linear power supply
- Built-in combiner for redundant backup supply
- Metal jacks, gold-plated XLRs, sealed pots and switches
- Individual circuit card assembly with nutted pots
- Solid copper bus bar grounding
- Sys-Link V2 console linking option
- 4-pin lamp sockets
