Apart Audio MASK6CT-BL 100V

The Apart Audio MASK6CT-B 100V is a 6.5" 2-way 100 V design speaker with ClickMount mount. The cabinet speakers have a unique design and crystal clear sound for all music applications from background music to dance volume music. It can be operated as a 70 V / 100 V loudspeaker with power taps for 60 - 30 - 15 - 6 and an additional 3 W at 70 V or as a low impedance loudspeaker with an impedance of 16 Ohm. MASK6C is therefore a versatile loudspeaker that can be used anywhere and in any application.

The housing is made of high-quality PP4 ABS plastic and the grille of aluminium. The high quality construction of the MASK6C guarantees a long life indoors and outdoors, even under extreme environmental conditions.MASK6C is based on a powerful 6.25" paper cone woofer with 1" silk dome tweeter and delivers high sound pressure with low distortion. This ensures superior clarity across the entire frequency spectrum. The integrated 3-stage protection circuit and high-quality components make the MASK6C a reliable, fail-safe loudspeaker even under high loads. The revolutionary ClickMount mount makes the MASK6C the easiest to install loudspeaker to install in record time. The pre-defined raster steps ensure perfect alignment for each speaker. With the discrete cable management system, the integrated spirit level and the input and output connectors, the complete cabling is done on the bracket. At the end of the installation, the loudspeaker is simply hooked into the ClickMount bracket.

Features:

• Housing loudspeakers with timeless design
• Full range speakers for background music or use in combination with a subwoofer when higher power is required.
• Unique 3-stage overload protection
• Suitable for indoor and outdoor use
• Wall and ceiling mounting possible
• Easy wall mounting with the supplied ClickMount bracket and integrated spirit level
• 200 W at 16 Ohm
• 70/100 V transformer (3 - 7.5 - 15 - 30 - 60 W) (3 W only 70 V)
• Coated 6.5" paper cone woofer, 1" silk dome tweeter
• 5° downward inclined vertical dispersion angle
• Rotatable Logo
• ABS plastic housing with painted aluminium grille
• Dimensions: 328 (H) x 198 (W) x 190 (D)
• Can be painted in any RAL colour
• Protection class IP 64
• Colour: black, white

Technical Specificatons:

• Model: MASK6CT
• Connections: Clip terminals
• Impedance: 16 Ohm, 70 / 100 V Transformer
• Power rating / output: 3 - 7.5 - 15 - 30 - 60 W (3 W only 70 V), 200 W at 16 Ohm
• Mounting: 6,5" woofer with coated paper cone 4.25" , 1" tweeter
• SPL, Sensitivity (1W /1m): 90 dB, 111 dB Peak
• Frequency response: 60 Hz - 20 kHz
• Design: 2-way system, incl. ClickMount mount, black, white
• Dimensions, weight: 328 x 198 x 190 mm (H x W x D), 3.9 kg
• Polar pattern: 180° H x 180° V

Specs:

• Color: Black
• Set Offer: no
• Power: 200 W
• 100V - Technique: yes
• Woofer: 1 x 6,5
• Tweeter: 1 x 1
• Type: Wall-mounted Loudspeaker
• Theme: Installation
