Boss WL-20L Wireless System

The Boss WL-20L Wireless System is a plug-and-play wireless system for guitar, bass and other electronic instruments. The WL-20L model is identical to the WL-20, but works without cable simulation. This makes the WL-20L perfect for instruments with no great capacitive effect on sound, including acoustic and electric guitars with integrated preamp and/or active pickups, as well as instruments with line level, such as a keytar (capsule keyboard) or the Roland Aerophone. In addition, the WL-20L works very well with passive pickup systems - especially if you don't value the subtle height attenuation provided by the cable simulation.

You've always dreamed of playing your instrument wirelessly, but you've been put off by the complicated setup, the loss of sound or the unwieldy accessories? In this case the WL-20 series is just right for you! Based on new, extremely fast BOSS technology, the ultra-compact systems deliver high-quality sound with easy plug-and-play operation, so you never again have to deal with the inconvenience of conventional wireless systems.

We are sure that once you get used to the uncomplicated wireless freedom of the WL-20 series, you will never again long for a cable on your instrument! Now that you don't have to worry about cable management, you can enjoy the new freedom to play at home, jamming with friends or on the live stage. Soundcheck lets you control your sound anywhere in the room to find the perfect settings for your audience. You can also interact better with your band mates and make your stage performance even more dynamic and entertaining.

Features:

• Plug-and-play wireless systems for guitar, bass and other electronic instruments
• No complicated setup required - just pair the transmitter and receiver for ten seconds to determine the optimal wireless connection
• Newly developed BOSS technology for premium sound without interference, extremely low latency (2.3 ms) and a range of up to 15 meters (with free line of sight)
• The integrated, rechargeable battery allows a continuous playing time of up to 12 hours
• Easy charging via a standard SB adapter (5 V / 500 mA or higher)
• Cable simulation that reproduces the natural capacitive effect of a 3m guitar cable (WL-20 model only)
• WL-T replacement transmitter available separately

Technical Specificatons Receiver:

• Wireless Format: BOSS proprietary digital audio format
• Wireless carrier frequency: 2.4 GHz
• Compatible Channels: 14
• Transmission Range: Up to 50 feet line-of-sight
• Latency: 2.3 ms
• Dynamic Range: 110 dB or greater
• Frequency Response: 20 Hz--20 kHz
• Nominal Input Level: -10 dBu
• Input Impedance: 1 k ohm
• Nominal Output Level: -10 dBu
• Output Impedance: 1 k ohm
• Recommended Load Impedance: 10 k ohms or greater
• Indicators: POWER, RECEIVE
• Connectors: Output plug: 1/4-inch TRS phone type; Transmitter jack: 1/4-inch TRS phone type; DC IN 5 V port: USB Micro-B type
• Power Supply: Rechargeable lithium-ion battery, Supplied from the DC IN 5 V port
• Current Draw: During wireless operation: 60 mA; While charging: 500mA
• Battery charging time: Charging only the receiver: Approximately 3 hours, Charging simultaneously with the transmitter: Approximately 4 hours
• Expected battery life under continuous use: Approximately 10 hours
• Accessories: Owner's Manual; Leaflet USING THE UNIT SAFELY; Transmitter; Micro USB cable for charging
• Width: 78 mm (3-7/16 inches)
• Depth: 25 mm (1 inches)
• Height: 38 mm (1-1/2 inches)
• Weight: 60 g (3 oz)

Technical Specificatons Transmitter (WL-T):

• Nominal Input Level: -10 dBu (1 M ohm)
• Indicator: Battery
• Connectors: Input plug: 1/4-inch TRS phone type; DC IN 5 V port: USB Micro-B type
• Power Supply: Rechargeable lithium-ion battery; Supplied from the DC IN 5 V port
• Current Draw: 350mA
• Battery charging time: Approximately 3 hours
• Expected battery life under continuous use: Approximately 12 hours
• Width: 87 mm (3-7/16 inches)
• Depth: 22 mm (7/8 inches)
• Height: 36 mm (1-7/16 inches)
• Weight: 43 g (2 oz)

Specs:

• Color: Black
• Set Offer: no
• Frequency band: 2.4 Ghz
• Type: Radio System
• Theme: Guitars and Basses

Instruction manual / Safety instructions:

• Manual (227.11 KB)
