DAP Club Mate 12 Product Details
The Club Mate speaker systems are especially designed for the mobile DJ's, where a powerful bass is required as well as a smooth mid–high frequency response. The 12" and 15" subwoofers have a long linear cone excursion to ensure minimal distortion and high power levels as well as to get a higher maximum sound pressure. Special attention is also given to the power ratings of the subwoofers and satellites as well as the behavior of all the independent dynamic compressors and limiter circuits inside.
Oct LR
- Subwoofer:12" compact vented active PA subwoofer
- Amplifier Output Low: 350 Watt RMSin 8 Ohm
- Amplifier Output High: 2x 120 Watt RMSin 8 Ohm
- Freq. Response (-3 dB): 50 – 125 Hz
- Crossover Freq.: 125 Hz, 24 dB/Oct BW
- Input Sensitivity: 0 dBu, 775 mV
- Efficiency (Half Space): 100 dB / W / m
- Max. SPL at 1 m (Theoret.): 125.4 dB
- Nominal Dispersion (HxV): 360° x 180°
- Dimensions (WxHxD): 452 x 515 x 603 mm
- Net Weight: 36 kg
- Satellites:6.5/1" passive vented PA satellite speaker system
- Freq. Response (-3 dB): 125 – 20,000 HzCrossover Freq.: 2700 Hz, 12 dB/
- Efficiency (Full Space): 95 dB / W / m
- Max. SPL at 1 m (Theoret.): 115.8 dB
- Nominal Dispersion (HxV): 90° x 60°
- Dimensions (WxHxD): 240 x 340 x 245 mm
- Net Weight: 9 kg
Specs:
- Type: Full Range Speaker
- Theme: PA and Sonication
