Soundsation MIOMIX 202UFX

The Soundsation MioMix 202UFX is a 4-channel mixer with digital multi-effects and USB sound card, which is ideal for small home recording, live gigging and podcasting applications where professional quality level and maximum portability are required. Two microphone inputs are equipped with noise-free preamps that accept all major sound sources, such as condenser mics, dynamic mics, line and high impedance inputs (guitars, basses, etc.). A stereo line input allows you to connect keyboards, CD players, DJ consoles, tablets or smartphones. Enhance your performance with the 24-bit/48 kHz digital effects with 16 commonly used presets (reverb/room/plate reverb, delay, echo, chorus, etc.) and the TAP tempo function, and adjust up to two parameters of each effect. Moreover, via the USB sound card with 24-bit/96 kHz stereo input and output, you can connect the unit to a computer and record or play back audio files in the highest quality.

Features:

• 2 mic/line channels with noise-free preamp, combo connector, Hi-Z input for guitars, +48V phantom power, peak meter.
• 1 stereo line channel with ¼" jack inputs, +4/-10dB pad adapter, and peak indicator
• 2-band EQ for channels 1 and 2
• 24-bit/48kHz 16 preset digital effect with TAP tempo and up to 2 adjustable parameters
• 24-bit/96kHz USB I/O stereo sound card with level control for playback
• Headphone monitor output with level control
• XLR main outputs with master level control
• Stereo 6-Led VU meter bar
• Rugged and lightweight metal enclosure for maximum flexibility and portability
• 240Vac - 5Vdc power adapter included

Specifications:

• Inputs: balanced XLR/jack combination (channel 1-2), balanced ¼" jack (channel 3-4).
• Output: Connector Balanced XLR (Main Out L-R), Stereo ¼" jack (Phones)
• USB connector: Type-B, female
• Channel 1-2 functions: +48V phantom power, impedance switch (Line/Hi-Z), 2-band EQ (80Hz/12kHz +/-15dB) effect send level, pan position, channel volume, peak led indicator
• Channel 3-4 functions: Impedance switch (+4/-10dB), 2-band EQ (80Hz/12kHz +/-15dB), effect send level, pan position, channel volume, peak LED indicator
• USB I/O sound card: Up to 24-bit/96kHz stereo input/output streaming, USB Class 2.0 compliant
• Digital effect: 24-bit sigma-delta, 256x oversampling, 48 kHz sampling rate
• Level meter: 2x6 LED display
• Maximum output level: 3 Vrms
• Frequency response: +/-0.5dB, 20Hz-20kHz
• Dynamic range: 102dB
• THD+N @ 1kHz: =0.003%
• Stereo Crosstalk: 92dB
• Power Requirements: DC 5V, 0.5A
• Power consumption: Max. 2.5W
• Power adapter: 100-240Vac - 0.15A / 5Vcc - 1A Max (power adapter included)
• Size (WxDxH): 166 x 165 x 66mm
• Net weight 0.9kg

Specs:

• Type: Mixer
• Theme: PA and Sonication
