XAOC Devices Tirana II

The XAOC Devices Tirana II is a compact, expandable voltage source with a wide range of uses including classic step sequencer, modulation source, voltage bank, and arpeggiator. Tirana is equally suited to small and large systems alike, either as a single utility or chained with more Tirana units.

Features:

• Four CV/gate steps
• Per-step repetition or ratcheting
• Per-step gate muting
• Accepts clock rates up to 320Hz
• On-board clock divider
• Voltage controlled play direction, transposition, and reset
• Dynamic gate width modulation
• Unipolar and bipolar adjustable voltage range
• Expandable by chaining more Tirana units
• Compatible with original Tirana units

Technical Specificatons:

• Eurorack standard synthesizer module
• wide: 6 HP
• powered: +12/-12V
• Reverse power protection
• Current draw: +30mA / –5mA

Specs:

• Type: Module
• Theme: Recording and Studio

Instruction manual / Safety instructions:

• Manual (1.74 MB)
