Acus STAGE Pre-3 Mixer

Pre-amplifier for acoustic PA, guitar, vocals and other acoustic instruments.

The innovative Stage Pre-3 is a professional preamplifier designed specifically for acoustic instruments and flexibility on stage. Stage Pre-3 is especially suitable when one or more guitars (or stig instruments) are used. With the Stage-REMOTE pedal, the tone adjustment of each channel can be made instantly at any time, whenever the guitar is changed. The Pre-3 can be positioned on a stand above the stage and can also be connected to monitors and extensions. With its comprehensive controls, minimalist design, compactness and light weight, this is a remarkably adaptable and attractive unit.

Features:

• Acus - STAGE Pre-3 Mixer
• 3 separately controllable channels
• Channel 1+2 with jack input, -10dB switch, Gain, High, Mid High, Mid Low, Low, Limiter, Flat 1-2 switch, Rev Vol, Volume,
• Channel 3 with combo jack-XLR socket, Gain, High, Mid High, Mid Low, Low,
• Rev Vol, Volume, Monitor section with volume for CH1, CH2, CH3 Notch filter for channel 1+2
• Master section: Effect selector for the 4 built-in digital effect reverb programs, switchable phantom power, mute switch, aux vol and phones control with jack output
• Channel 1-3: XLR Direct-Out, Send, Return
• Outputs: Master L/R (XLR), AUX L/R, Tuner, Monitor, Foot-Switch 1+2, Adapter for floor stand
• Phantom power: 36V DC, with PH switch and LED
• Housing: metal (black) + side panels in laminated wood (wood nature)
• Freq. bandwidth: 20 Hz-20k Hz
• Mixer section: 3 channels + aux preamp
• weight: 2 kg
• Dimensions: H 5 cm, W 18 cm, D 30 cm

Specs:

• Type: Mixer
• Theme: PA and Sonication

Instruction manual / Safety instructions:

• Manual (3.99 MB)
