ANT ANTMIX 6 FX

This small mixer has 6 channels. Due to its small size it is very handy and has only a low weight. On channel 1 and 2 is also an XLR connector with phantom power of 48V.

Features:

• 6 channels (2 x mono Mic/Line: XLR/TRS jack; 2 x stereo: RCA/jack).
• 48V phantom power on channel 1 and 2
• 16 digital effects integrated (e.g. reverb, delays, plate, chorus), muteable via footswitch (jack)
• Master section with mastermute, peak LED, output level, 2-TK send and adjustable 2-TK return
• Outputs: Main Mix (TRS jack), Control Room (TRS jack) and Phones (6.3mm stereo jack), 2TK-Out (RCA)

Technical data:

• MONO Mic/Line inputs 2
• Mic Mono/Stereo Line Inputs -
• Stereo Line Input 2
• Dimensions (W x H x D) 196 x 68 x 243 mm
• Weight 1,18 Kg
• Connector Balanced XLR
• Impedance 1,8 kΩ
• Frequency range 20~20kHz +/-1dB
• Distortion (THD + N) <0.03% @ +0dB, 22~22 kHz, A weighted
• Gain 0~55dB
• Max. Input +15dB (balanced)
• Low cut 75Hz 12dB/oct.
• Signal-to-noise ratio <-100 dBr A weighted
• Phantom power +48V

Specs:

• Type: Mixer
• Theme: PA and Sonication
