Drawmer DS501 Power Gate Product Details
The DS501 is a sophisticated Punch 2-channel noise gate with fully tunable peak and contains a wealth of audio engineers for many essential features that are not found in conventional noise gates.
Located in the Drawmer range above the industry standard DS201, DS501 which a new dual, tunable Peak Punch mode has for each channel. The tunable mode the user can influence a selector with a frequency range from 75Hz to 16kHz, the transients of the gated signal, and "agree" to a specific region of the spectrum, where the peak will be Punch. An additional controller can be adjusted while the degree of influence accurately. A second full-range Peak Punch mode is also available.
Developed primarily for the gating percussive signals, it is the tuneable Peak Punch manages the processing of transients, add a single sound more punch and gives the gated signal to more definition and presence in the mix.
Punch low-frequency peak gives thin drum sounds more volume, while high-frequency peak punch rim shots, or the attack of a snare can dynamically increase.
Features:
- tunable peak Punch
- variable high-and low-pass filter for frequency-selective gating
- extensive lope, Attack, Hold, Decay, and Range
- Key input for external triggering
- "Key-Listen" Function
- extremely fast Attack-time
- balanced In- and Outputs
- stereo coupling
- used for "Gating" or "ducking"
- high Audio quality
- Input impedance: 20k Ohm
- Input level(max.): +17dBu
- Output impedance: 50 Ohm
- Output level(max.): +17dBu
- noise Ratio: -90dB
- Distortion: < 0,025%
- Frequency response: 23Hz-31kHz -1dB
- Power consumption: 115V or 230V, 9 W
- Dimensions: 19", 1HE
- weight: 3,4 kg
Specs:
- Type: digital Effects Processor
- Theme: Recording and Studio
