EUROLITE LED TMH-X4 Moving-Head Wash Zoom

The EUROLITE LED TMH-X4 Moving-Head Wash Zoom features 19 powerful 15W RGBW LEDs and 16 or 24 selectable DMX channels. Special features of the moving head are the stepless RGBW color mixing, the preset colors, the color change and the color fading. The moving head is air cooled.

Features:

• 19 powerful 15W RGBW LEDs (4in1)
• 16 or 24 DMX channels selectable
• Three different LED segments that can be controlled individually via DMX
• Positioning within 540° PAN and 270° TILT
• Stepless RGBW color mixing, preset colors, color change and color fading
• Integrated show programs in auto and music mode
• Strobe effect with variable speed
• Strobe effect via random generator
• Dimmer
• Motorized zoom with 1-25° beam angle
• Compatible with QuickDMX - the wireless DMX system from Eurolite
• Phantom powered USB socket for QuickDMX receiver (accessory)
• Music control via built-in microphone with adjustable microphone sensitivity
• Automatic position correction
• Exact positioning due to 16-bit resolution of PAN/TILT movement
• Fan cooled
• Auto, music, master/slave and DMX mode
• Control board with color LCD for setting DMX start address, PAN/TILT reverse, reset
• P-Con power connectors for easy interconnection of up to 8 units
• Switching power supply technology for mains voltage between 100 and 240 volts
• Control: stand-alone; QuickDMX via USB possible; DMX
• Projection: flicker-free

Technical data:

• Power supply: 100-240 V AC, 50/60 Hz
• Total connected load: 225 W
• Protection class: IP20
• Power connection: Power supply P-Con (blue), built-in version Power connection cable with protective contact
• Power output: P-Con (gray), built-in version
• Fuse: 5 x 20 mm T slow blow, 2 A fuse replaceable
• LED: 19 x COB (chip-on-board) 15 W 4in1 QCL RGBW (homogeneous color mixing)
• Max. TILT: Exact positioning (16 bit resolution) 270° Auto position correction (feedback)
• Max. PAN: Exact positioning (16-bit resolution) 630° Auto position correction (feedback)
• Features: Zoom motorized
• DMX channels: 16; 24
• DMX input: 1 x 3-pin XLR (M) built-in version
• DMX output: 1 x 3-pin XLR (W) built-in version
• Fan: temperature controlled head; base
• Control: stand-alone; QuickDMX via USB possible; DMX
• Beam angle: 1 - 25

Specs:

• Beam: Wash
• Light source: LED RGBW
• Colour mixing: LED
• Gobo: none
• Focus: no
• Steuerung DMX: yes
• Type: Moving Head
• Theme: Light and Show

Instruction manual / Safety instructions:

• Manual (3.08 MB)
