EUROLITE DMX AIO Recorder, Merger, Artnet Node, Signalwandler

The wireless DMX recorder for two universes can record and play back light shows in real time via DMX and WLAN. Any Art-Net and DMX source can be recorded. The recorder can be used directly via Android and iOS apps. (e.g. Aurora DMX, Photon, ArtNetDmxRemote). The data is stored using the 16 GB SD card supplied.

Features:

• Wireless DMX recorder and Art-Net-Node
• 2 DMX universes (1024 DMX channels)
• Recording and playback of light shows in real time via DMX and WLAN
• Any Art-Net and DMX source can be recorded
• Built-in access point
• Direct operation via Android and iOS Apps (e.g. Aurora DMX, Photon, ArtNetDmxRemote)
• Art-Net In/Out via WLAN or network socket
• 8 memory locations with up to 20 hours recording capacity each
• Storage on included SD card (16 GB)
• 2 recording modes: time recording or step-by-step
• 2 playback modes: single playback or continuous loop
• Dimmer and speed controller
• DMX Merger (2 In > 1 Out) with HTP, LTP, Override, Backup modes
• DMX splitter (1 In > 2 Out)
• Configuration via operating keys and LCD display
• Power supply via P-Con socket or USB connection
• Robust black metal housing
• Control: DMX
• PC connect: USB

Technical data:

• Power supply: 100-240 V AC, 50/60 Hz or 5 V DC 500 mA
• Total connected load: 4 W
• DMX input: 2 x 3-pin XLR (M) built-in version
• DMX output: 2 x 3-pin XLR (W) built-in version
• Current output: 1 x P-Con (grey), built-in version
• Dimensions: W 22.70 x H 7.00 x D 13.00 cm
• Weight: 1,17 kg

Instruction manual / Safety instructions:

• Manual (1.26 MB)
